AURORA™ Pastel Yellow - Model 2017

This guitar was built in 2017. This is the fourth electric guitar ever made by Stapleton Guitars.

Solid white ash body in pastel yellow colour, semi gloss waterbased clear polyurethane finish. Hard Maple pickguard loaded with handmade overwound aged white humbucker pickups. Maple neck and maple fingerboard with Jescar stainless steel frets.

This guitar features high quality components such as Sperzel Trim-Lok nickel plated tuning machines, Graphtech TUSQ nut and contemporary saddles, and Elixir Nanoweb strings.

Specification

NECK

• NECK WOOD: Hard Maple
• NECK BINDING: 1-ply White
• NECK STRIP: None
• FINGERBOARD WOOD: Hard Maple
• FINGERBOARD RADIUS: 9.5 in (241.3mm)
• FINGERBOARD INLAYS: Black dots
• SIDE DOTS: Black dots
• SCALE LENGTH: 25.5 in (648 mm)
• NUT MATERIAL: Graphtech TUSQ
• NUT WIDTH: 42mm
• NUMBER OF FRETS: 22
• FRETS MATERIAL: Jescar Stainless Steel .095″ X .047 (2.41 X 1.19 mm)
• TUNING MACHINES: Sperzel Trim-Lok Nickel Plated
• TRUSS ROD: Double Action
• NECK JOINT: Bolt-On
• NECK FINICH: Semi Gloss Waterbased Clear Polyurethane
• HEADSTOCK SHAPE: Original AURORA
• HEADSTOCK VENEER: None
• HEADSTOCK LOGO: Silver
• HEADSTOCK INLAY: None
• HEADSTOCK PURFING: None

ELECTRONICS

• NECK PICKUP: High output Aged White (50mm) humbucker pickup Alnico 5
• BRIDGE PICKUP: High output Aged White (53mm) humbucker pickup Alnico 2
• SWITCH: 6 Position Rotary Switch

BODY

• BODY TOP WOOD: None
• BODY WOOD: Pastel Yellow
• BODY COLOUR: Aged White
• BODY WIDTH: 335mm
• BODY LENGTH: 445mm
• BODY DEPTH: 45mm
• BODY BINDING: 1-ply White
• BODY FINISH: Semi Gloss Waterbased Clear Polyurethane
• BODY STRIP: None
• PICKGUARD MATERIAL: Hard Maple
• PICKGUARD COLOUR: Aged White
• BRIDGE STRING SPACING: 54mm

HARDWARE

• BRIDGE: Nickel Plated Brass
• SADDLES: Contemporary Chrome Plated
• VOLUME KNOB: Cupcake Chrome Plated
• TONE KNOB: Black Metal Roller Knob
• SWITCH KNOB: Black Metal Roller Knob
• NECK PLATE: Nickel Plated Brass
• JACK PLATE: Curved Rectangular Metal Nickel Plated
• STRAP BUTTON: Oversized Nickel Finish
• JACK STRAP BUTTON: Endpin Jack Strap Button Stainless Steel

MISC

• STRINGS: Elixir Nanoweb Light 10/46
• BAG OR CASE: Hard Case
