AURORA™ Graphite - Model 2018

The guitar was built in 2018. Has a different body shape from 2017 model.

Solid white ash body in aged white colour, semi gloss waterbased clear polyurethane finish. Black Walnut pickguard loaded with handmade overwound black humbucker pickups. Maple neck and maple fingerboard with Jescar stainless steel frets.

This guitar features high quality components such as Sperzel Trim-Lok nickel plated tuning machines, Graphtech TUSQ nut and saddles, and Elixir Nanoweb strings.

Specification

NECK

• NECK WOOD: Hard Maple
• NECK BINDING: None
• NECK STRIP: None
• FINGERBOARD WOOD: Hard Maple
• FINGERBOARD RADIUS: 9.5 in (241.3mm)
• FINGERBOARD INLAYS: Black dots
• SIDE DOTS: Black dots
• SCALE LENGTH: 25.5 in (648 mm)
• NUT MATERIAL: Graphtech TUSQ
• NUT WIDTH: 45mm
• NUMBER OF FRETS: 23
• FRETS MATERIAL: Jescar Stainless Steel .095″ X .047 (2.41 X 1.19 mm)
• TUNING MACHINES: Sperzel Trim-Lok Nickel Plated
• TRUSS ROD: Double Action
• NECK JOINT: Bolt-On
• NECK FINICH: Semi Gloss Waterbased Clear Polyurethane
• HEADSTOCK SHAPE: Original AURORA
• HEADSTOCK VENEER: None
• HEADSTOCK LOGO: Silver
• HEADSTOCK INLAY: None
• HEADSTOCK PURFING: None

ELECTRONICS

• NECK PICKUP: HOT - Aged White neck (50mm) humbucker pickup Alnico 5
• BRIDGE PICKUP: HOT - Aged White bridge (53mm) humbucker pickup Alnico 2
• SWITCH: 6 Position Rotary Switch

BODY

• BODY TOP WOOD: None
• BODY WOOD: White Ash
• BODY COLOUR: Aged White
• BODY WIDTH: 340mm
• BODY LENGTH: 450mm
• BODY DEPTH: 42mm
• BODY BINDING: 1-ply Cream
• BODY FINISH: Semi Gloss Waterbased Clear Polyurethane
• BODY STRIP: None
• PICKGUARD MATERIAL: Black Walnut
• PICKGUARD COLOUR: Transparent Dark Red
• BRIDGE STRING SPACING: 54mm

HARDWARE

• BRIDGE: Nickel Plated Brass
• SADDLES: Graphtech TUSQ
• VOLUME KNOB: Cupcake Chrome Plated
• TONE KNOB: Black Metal Roller Knob
• SWITCH KNOB: Black Metal Roller Knob
• NECK PLATE: Nickel Plated Brass
• JACK PLATE: Curved Rectangular Metal Nickel Plated
• STRAP BUTTON: Oversized Nickel Finish
• JACK STRAP BUTTON: Endpin Jack Strap Button Stainless Steel

MISC

• STRINGS: Elixir Nanoweb Light 10/46
• BAG OR CASE: Hard Case
